DIN RAIL POWER SUPPLY 24W/12VDC/2A ULTRA SLIM HDR-30-12 MEAN WELL

Output Voltage: 12V DC
Output Current: 2A
Output Power: 24W
Voltage Adjustment Range: 10.8 – 13.2V
Input Voltage Range: 85 – 264V AC / 120 – 370V DC
Efficiency: Up to 88%
Line/Load Regulation: ±1.0%
Ripple & Noise: 120mVp-p
Setup Time: 500ms / 230VAC
Hold-up Time: 30ms / 230VAC
Protections: Overload (105–160%), Overvoltage with clamp
Operating Temperature: -30 to +70°C
Cooling: Free air convection
Mounting: DIN rail TS35/7.5 or TS35/15
Operating Altitude: Up to 2000m
LED Power Indicator: Yes
Dimensions: 35 x 90 x 54.5 mm
Weight: 130g
Certifications: UL62368-1, UL508, TUV EN61558-2-16, IEC62368-1, EAC TP TC 004
MTBF: 3,670,400 hours (Telcordia SR-332)
Technical Specs

Code: 07.00016

Availability: Available

19.46€

/ Item

Wishlist

Compare products

Description

The HDR-30-12 by Mean Well is a compact 24W DIN rail power supply delivering 12V DC at 2A. With its ultra-slim 35mm step shape design, it is ideal for space-restricted electrical panels. It features adjustable output from 10.8 to 13.2V, with high efficiency up to 88%, and includes protections against overload (105–160%) and overvoltage.

The unit operates fanlessly via natural convection and supports a wide input range from 85–264VAC or 120–370VDC. It includes a power-on LED, is mountable on standard DIN rails, and complies with major international safety and EMC standards. With an MTBF of over 3.6 million hours, the HDR-30-12 is a reliable choice for industrial, automation, and smart home systems.
