DIN RAIL POWER SUPPLY 54W/12VDC/4.5A ULTRA SLIM HDR-60-12 MEAN WELL

Output Voltage: 12V DC
Output Current: 4.5A
Output Power: 54W
Adjustment Range: 10.8 – 13.2V
Voltage Tolerance: ±1.0%
Line / Load Regulation: ±1.0%
Ripple & Noise: 120mVp-p
Input Voltage Range: 85 – 264VAC / 120 – 370VDC (up to 277VAC / 390VDC operational)
Frequency Range: 47 – 63Hz
Efficiency (typical): 88%
Input Current: 1.2A / 115VAC, 0.8A / 230VAC
Inrush Current: 30A / 115VAC
Setup / Rise Time: 500ms, 50ms
Hold-up Time: 30ms / 230VAC, 12ms / 115VAC
Protections:
- Overload: 105 – 160% (hiccup mode, auto recovery)
- Overvoltage: 13.5 – 18V (shut down and re-power to recover)
Operating Temperature: -30°C to +70°C
Humidity: 20% – 90% RH non-condensing
No Load Power Consumption: <0.3W
Cooling: Free air convection
Mounting: DIN rail TS35/7.5 or TS35/15
Dimensions: 52.5 x 90 x 54.5 mm
Weight: 190g
MTBF: 3,524,800 hours (Telcordia SR-332)
Certifications: UL62368-1, UL508, TUV EN61558-2-16, EN62368-1, EAC, BSMI, BIS IS13252
Technical Specs

Code: 07.00025

Availability: Available

27.63€

/ Item

Wishlist

Compare products

Description

The Mean Well HDR-60-12 is a 54W DIN rail mount power supply delivering 12V DC at 4.5A. Designed with a compact 52.5mm width, it fits easily in standard distribution panels and offers high energy efficiency of up to 88%. It accepts a wide input voltage range of 85–264VAC and remains operational up to 277VAC, making it ideal for global industrial and automation systems.

It features full protection functions including overload (105–160%) and overvoltage (13.5–18V), and operates silently via natural air convection. With a wide operating temperature range (-30°C to +70°C), low no-load power consumption (<0.3W), and international safety and EMC certifications, the HDR-60-12 is a reliable, space-saving solution for control panels, automation systems, LED lighting, and building management installations.

DIN RAIL POWER SUPPLY 54W/12VDC/4.5A ULTRA SLIM HDR-60-12 MEAN WELL
