DIN RAIL POWER SUPPLY 60W/12VDC/5A PFC ULTRA SLIM MDR-60-12 MEAN WELL
- Output Voltage: 12V DC
- Output Current: 5A
- Output Power: 60W
- Adjustment Range: 12 – 15V
- Voltage Tolerance: ±1.0%
- Line / Load Regulation: ±1.0%
- Ripple & Noise: 120mVp-p
- Input Voltage Range: 85 – 264VAC / 120 – 370VDC
- Frequency Range: 47 – 63Hz
- Efficiency (typical): 85%
- Input Current: 1.8A / 115VAC, 1A / 230VAC
- Inrush Current: 30A / 115VAC, 60A / 230VAC
- Setup / Rise Time: 500ms, 30ms @ 230VAC; 500ms, 30ms @ 115VAC
- Hold-up Time: 50ms @ 230VAC; 20ms @ 115VAC
- Protections:
- Overload: 105 – 150% (constant current limiting, auto recovery)
- Overvoltage: 15.6 – 18V (shut down, re-power to recover)
- Short circuit
- Operating Temperature: -20°C to +70°C (with derating above +55°C)
- Humidity: 20% – 90% RH non-condensing
- Cooling: Free air convection
- Dimensions: 40 x 90 x 100 mm
- Weight: 0.33 kg
- MTBF: 2,355,200 hours (Telcordia SR-332)
- Certifications: UL508, UL62368-1, TUV EN/BS EN62368-1, EAC TP TC 004, BSMI, BIS IS13252, IEC60950-1, AS/NZS 60950.1
- EMC Compliance: EN55032 class B, EN61204-3, EN61000-6-2, EN61000-3-2
- Technical Specs
