DIN RAIL POWER SUPPLY 96.6W/27.6VDC/2.25A WITH BATTERY CHARGER (UPS) DRC-100B MEAN WELL
- Output Voltage: 27.6V DC
- Output Current: 2.25A
- Output Power: 96.6W
- Adjustment Range: 24 – 30V
- Voltage Tolerance: ±1.0%
- Line / Load Regulation: ±0.5%
- Ripple & Noise: 240mVp-p
- Input Voltage Range: 90 – 264VAC / 127 – 370VDC
- Frequency Range: 47 – 63Hz
- Efficiency (typical): 89%
- Input Current: 1.8A / 115VAC, 1.1A / 230VAC
- Inrush Current: 30A / 115VAC, 60A / 230VAC
- Setup / Rise Time: 2400ms, 50ms / 230VAC; 2400ms, 50ms / 115VAC
- Hold-up Time: 50ms / 230VAC; 10ms / 115VAC
- Protections:
- Overload: 105 – 150% (hiccup mode, auto recovery)
- Overvoltage: 31.2 – 36V (shut down, re-power to recover)
- Short circuit
- Operating Temperature: -30°C to +70°C (with derating)
- Humidity: 20% – 90% RH non-condensing
- Cooling: Free air convection
- Dimensions: 55 x 90 x 100 mm
- Weight: 0.37 kg
- MTBF: 1,820,400 hours (Telcordia SR-332)
- Certifications: UL62368-1, TUV EN/BS EN62368-1, EAC TP TC 004, AS/NZS 60950.1
- EMC Compliance: EN55032 class B, EN61204-3, EN61000-6-2
- Technical Specs
Code:
07.00033
Availability:
Available
64.53€
/ Item
