DIN RAIL SWITCH DISCONNECTOR 1P 40A 230/400VAC EPI-R MAXGE

Device type: Isolator switch
Poles: 1P
Rated current (In): 40A
Rated operational voltage (Ue): 230/400VAC
Rated insulation voltage (Ui): 690V
Short-circuit making capacity (Icm): 20 Ie
Utilization category: AC-22A
Impulse withstand voltage (Uimp): 6kV
Mechanical endurance: ≥10,000 cycles
Electrical endurance: ≥1,500 cycles
Operating temperature: -5°C to +35°C
Protection degree: IP20
Width: 17.8 mm
Mounting: DIN rail 35mm
Compliance: EN/IEC 60947-3

Code: 07.00095

Availability: Available

2.11€

/ Item

Wishlist

Compare products

Description

The EPI-R 1P 40A isolator switch by Maxge is designed for the disconnection of single-phase circuits in distribution panels. With an AC-22A utilization category and a short-circuit making capacity of 20 Ie, it ensures safe and reliable load isolation under demanding conditions.

Easy to install on a 35mm DIN rail, the device features an IP20 protection rating and a compact 17.8 mm width. Compliant with EN/IEC 60947-3, it is ideal for residential, commercial, and light industrial applications requiring secure circuit isolation.
