FRP MEMBRANE HOUSING 2.5″ END-PORT MODEL, SUITABLE FOR 40 INCH RO ELEMENTS - H.S. 84219990

(Preview 1) FRP MEMBRANE HOUSING 2.5″ END-PORT MODEL, SUITABLE FOR 40 INCH RO ELEMENTS - H

(Thumb 1) FRP MEMBRANE HOUSING 2.5″ END-PORT MODEL, SUITABLE FOR 40 INCH RO ELEMENTS - H.S

FRP MEMBRANE HOUSING 2.5″ END-PORT MODEL, SUITABLE FOR 40 INCH RO ELEMENTS - H.S. 84219990

FRP 2.5″ end-port membrane housing for 40″ element
Operating pressure 1000 psi
Super duplex AISI 2507 end-caps
1/4″ BSPT F connections
Length 1112 mm – Support span 700 mm

Code: 02.00111

Availability: Available

505.44€

/ Item

Wishlist

Compare products

Description

The H2E1G1 membrane housing is engineered for high-pressure RO applications, designed to accommodate a 40″ membrane element and operate at 1000 psi. Its fiberglass-reinforced FRP body with UV-protected white coating ensures long-term durability under demanding conditions. The super duplex AISI 2507 end-caps provide exceptional mechanical and corrosion resistance.

It features 1/4″ BSPT F ports for feed, concentrate and permeate, while its 1112 mm total length and 700 mm support span allow straightforward installation and secure mounting. Fully PED compliant, the housing is suitable for professional reverse osmosis systems and industrial water treatment applications.
