LOCKING CLIP FOR OD12 - 1/2 , BLUE - HCP12-1/2BL

Product Type: Push-fit socket locking clip
Size Compatibility: For compatible sockets for Ø12 mm or 1/2 in outside-diameter tubing
Manufacturer Code: HCP12-1/2BL
Color: Blue
Installation Method: Between the socket body and its release collar
Function: Restricts accidental depression of the release collar
Circuit Role: Mechanical connection locking; not a sealing element
Applications: Tube connections in filters, water treatment and food and beverage equipment

Code: 01.00606

Availability: Available

0.11€

/ Item

Wishlist

Compare products

Description

The HCP12-1/2BL is a Fluid-fit locking clip for compatible sockets used with Ø12 mm or 1/2 in outside-diameter tubing. It fits between the body and release collar to reduce the risk of accidental operation of the disconnection mechanism.

The clip is used after the tube has been fully inserted and its retention checked. It does not replace correct assembly, seal the connection, or act as a tube or valve mounting bracket. It must match the particular fitting series and socket geometry. The metric and inch sizes refer to sockets compatible with the same clip, not to interchangeable tubing.

Fully depressurise the circuit before removing the clip and disconnecting the tube. The clip does not increase the push-fit connector’s allowable operating pressure or temperature. It is used for:
