MINIATURE CIRCUIT BREAKER 1P B 16A 6kA 230/400VAC EPB-63M MAXGE

  • Device type: Miniature Circuit Breaker (MCB)
  • Poles: 1P
  • Tripping curve: B
  • Rated current (In): 16A
  • Breaking capacity (Icn): 6kA
  • Rated operational voltage (Ue): 230/400VAC
  • Frequency: 50/60Hz
  • Insulation voltage (Ui): 500V
  • Width: 18 mm
  • Mounting type: DIN rail 35mm
  • Protection degree: IP20 (when installed)
  • Electrical endurance: ≥10,000 operations
  • Mechanical endurance: ≥20,000 operations
  • Compliance: IEC/EN 60898-1, IEC/EN 60947-2
Code: 07.00103
Availability: Available
1.67€
/ Item

Share

Description

The EPB-63M 1P B 16A MCB by Maxge is designed for the protection of low inrush current circuits, such as lighting and general-purpose lines. The B curve provides faster tripping under short-circuit or overload conditions, making it ideal for sensitive circuits.

With a compact 18mm design and DIN rail mount, it is well-suited for residential and commercial panels. Fully compliant with IEC/EN standards, it ensures reliable safety and performance.



Features
