POWER SUPPLY 102W/12VDC/8.5A ULTRA MINI LRS-100-12 MEAN WELL

Output Voltage: 12V DC
Output Current: 8.5A
Output Power: 102W
Adjustment Range: 10.2 – 13.8V
Ripple & Noise: 120mVp-p
Voltage Tolerance: ±0.5%
Line / Load Regulation: ±0.5%
Input Voltage Range: 85 – 264VAC / 120 – 373VDC
Frequency Range: 47 – 63Hz
Efficiency: 86%
Input Current: 1.9A / 115VAC, 1.2A / 230VAC
Inrush Current: 50A / 230VAC
Setup / Rise Time: 500ms, 30ms / 230VAC
Hold-up Time: 55ms / 230VAC, 10ms / 115VAC
No Load Power Consumption: <0.3W
Protections:
- Short Circuit (hiccup mode, auto recovery)
- Overload: 110–150%
- Overvoltage: 13.8 – 16.2V (shutdown, re-power to recover)
Operating Temperature: -30°C to +70°C
Cooling: Free air convection
Dimensions: 129 x 97 x 30 mm
Weight: 0.33kg
MTBF: 3,348,900 hours (Telcordia SR-332)
Certifications: UL62368-1, TUV EN62368-1, EN60335-1, EN61558-1/-2-16, GB4943.1, EAC
EMC Compliance: EN55032 class B, EN61000-6-2, EN55035
Other Features: 5G vibration resistance, 5000m altitude, ultra-low 30mm profile
Technical Specs

Code: 07.00023

Availability: Available

21.27€

/ Item

Wishlist

Compare products

Description

The Mean Well LRS-100-12 is a compact, enclosed AC-DC switching power supply delivering 12V DC at 8.5A, with a total output power of 102W. Designed for industrial and control panel applications, this model features a low profile (30mm height), high efficiency up to 86%, and an ultra-low no-load power consumption of <0.3W, making it suitable for energy-conscious systems.

The unit offers a universal AC input (85–264VAC) and full protection functions including short circuit, overload (110–150%), and overvoltage (13.8–16.2V), ensuring safe and stable operation. It operates from -30°C to +70°C with free air convection, without the need for a fan. The rugged metal case and perforated enclosure optimize heat dissipation and mechanical reliability.

Certified to international safety standards (UL, TUV, EN62368-1, EAC), the LRS-100-12 is ideal for use in LED lighting, automation equipment, industrial control, and electrical distribution panels, offering high MTBF (>3.3 million hours) and consistent, long-term performance.
