UNION CONNECTOR 3/4 - 5/8 - HUC0605B

Product Type: Straight reducing union connector
Connection Dimensions: Tubing outer diameters Ø6 mm and Ø5 mm
Color: Black
Material: High-quality acetal plastic POM (polyoxymethylene)
Connection Mechanism: Push-to-connect at both ends
Operating Pressure: Up to 150 psi (pounds per square inch), approximately 10.3 bar, subject to the manufacturer's temperature and tubing limits
Temperature Range: 0°C to +65°C
Applications: Water treatment systems, pneumatic networks, low-pressure auxiliary desalination circuits, food and beverage equipment

Code: 01.00399

Availability: Available

Minimum quantity: 2 items

1.98€

/ Item

Wishlist

Compare products

Description

The HUC0605B is a Fluid-fit straight reducing union connector for joining tubing with outer diameters of Ø6 mm and Ø5 mm. It has two differently sized sockets in an in-line configuration, providing a transition between the two tubing diameters.

Made from high-quality acetal plastic POM (polyoxymethylene), it incorporates EPDM (ethylene propylene diene monomer rubber) sealing. Push-to-connect sockets at both ends enable quick tube insertion without tools. Each tube must match the outer diameter specified for its socket and be suitable for the operating conditions of the installation.

The operating temperature range is 0°C to +65°C, with a pressure ceiling of up to 10.3 bar under suitable conditions. The allowable pressure is not the same at every temperature and must be checked against the manufacturer's table and the limits of the connected tubing. Disconnect only after the line has been fully depressurized. Subject to media compatibility and operating conditions, applications include:
